ABB MFE190-04UD-09A0-2 Servo Drive | Single Phase 200–240VAC Industrial Motor Driver

ABB MFE190-04UD-09A0-2 Servo Drive | Single Phase 200–240VAC Industrial Motor Driver

ब्रांड नाम: ABB
मॉडल संख्या: MFE190-04UD-09A0-2
एमओक्यू: 1
कीमत: Negotistical
विस्तृत जानकारी
उत्पत्ति के प्लेस:
OEM
इनपुट वोल्टेज:
1/3~200...240 वी एसी
आगत बहाव:
20ए
इनपुट आवृत्ति:
50/60 हर्ट्ज
आउटपुट वोल्टेज:
3~0...उ1
आउटपुट करेंट:
9ए नाममात्र
अधिभार क्षमता:
7.5ए 300% 3एस ओवरलोड
आउटपुट आवृत्ति:
0...500 हर्ट्ज
शीतलक:
हवा ठंडी करना
संरक्षण वर्ग:
आईपी20
पैकेजिंग विवरण:
नया मूल बॉक्स
उत्पाद का वर्णन
ABB MFE190-04UD-09A0-2 Servo Drive
The ABB MFE190-04UD-09A0-2 is a compact, high-performance single-phase servo drive from ABB's MicroFlex e190 series, designed for precise and flexible industrial motion control. Rated for 200-240VAC single-phase input with a 9A continuous current output, it delivers stable power output and exceptional dynamic response for small-to-medium automation machinery.
Key Features
  • Single-phase 200-240VAC input with 9A continuous current output
  • Supports multiple motor types: synchronous servo, asynchronous induction, and linear servo motors
  • Robust overload capacity: 200% for 3 seconds and 300% peak overload
  • Advanced 8kHz PWM vector modulation technology with over 95% efficiency
  • Integrated multi-protocol Ethernet interfaces (EtherCAT, PROFINET IO, Modbus TCP/IP)
  • Universal encoder feedback options and rich digital & analog I/O ports
  • Lightweight and rugged frame design with wide temperature range operation up to 55°C
  • Compliant with EU ecodesign standards with comprehensive protection functions
Technical Specifications
Input Voltage 200-240VAC Single Phase
Continuous Current 9A
Overload Capacity 200% for 3 seconds, 300% peak
Efficiency >95%
Operating Temperature Up to 55°C
Communication Protocols EtherCAT, PROFINET IO, Modbus TCP/IP
Applications
Ideal for: Packaging equipment, automated assembly lines, CNC machinery, and small industrial automation systems. Serves as a cost-effective and high-reliability motion control solution.
