| ब्रांड नाम: | MITSUBISHI |
| मॉडल संख्या: | AJ65BT-D62 |
| एमओक्यू: | 1 |
| कीमत: | Negotiations |
| Parameter | Specification |
|---|---|
| Number of Channels | 2 |
| Counting Speed (Max) | 200k pulses/second (1-phase input), 200k pulses/second (2-phase input) |
| Count Input Signal Level | DC 5V, 12V, 24V (2-5 mA) |
| Counting Range | 24-bit signed binary (0 to 16,777,215) |
| External Input Signal | DC 5V, 12V, 24V (2-5 mA) |
| Coincidence Output | Transistor output (open collector), DC 12/24V, 0.5A |
| Response Time (Output) | ≤ 0.1 ms |
| I/O Module Power Supply | DC 18.0 - 28.8V, 70 mA |
| Occupied Stations (CC-Link) | 4 stations |
| External Connection | Terminal block type (M3.5 screws) |
| Dimensions (H × W × D) | 65 mm × 151.9 mm × 63 mm |
| Weight | 0.41 kg |
| Series | CC-LINK |
|---|---|
| Type | REMOTE HIGH-SPEED COUNTER |
| Power Supply (V) | 24 |
| Current Type | DC |
| Number of Channels | 2 |
| Int. Current Consumption (A) | 0,07 |
| Depth (mm) | 65 |
|---|---|
| Weight (kg) | 0,41 |
| Width (mm) | 151 |
| Height (mm) | 63 |
